Schematics L340-15IRH (81LK) FG541 FG741 NM-C362

Star Rating

5.00 star(s)

L340-15IRH (81LK) FG541 FG741 NM-C362 Schematics, BIOS
L340-15IRH Gaming, L340-17IRH Gaming BGCN24WW 9th.bin
NM-C362 KB_pins=32 LEFT UP 08MM PD0=13 PD1=17 PD2=19 PD3=24 PD4=20 PD5=16 PD6=23 PD7=21 BUSY=10 STB=18 AFD=7 INIT=14 SLIN=15 KSI4=11 KSI5=12
Lenovo L340-17IRH Gaming - NM-C362 BoardView.tvw



[ptkiba]

any bv?



[ThienBui]

any bv?

Unavailable



[caco666]

only one version

Ok, thanks. I am not sure if I have the right schematics. I can't find PU904 (page 52). Is it supposed to be PU401?

I would also like to check if my IT8586E is ok. What's the best way? It's a laptop that had a short between the middle pin and VIN due to a broken power jack. Thanks



[laptech]

plz build bios no display



[ThienBui]

plz build bios no display



[osman68i]

hi,

laptop start no display.

tried all bios but no display.



[ThienBui]

tried all bios but no display.

This shows that the laptop does not have BIOS error



[osman68i]

ok.



[Abbas ALi]

sir clear thi bios no display



[Abbas ALi]

sir clear thi bios no display



[ThienBui]

clear me



[dzaro5]

I am looking for a Biosu / EC for this Lenovo L340-17IRH laptop FG541 / FG741 NM-C362 REV.1.0 2019-03-19 motherboard.
I tried various available ones and the problem with them is that on some the laptop does not display the image on the matrix, but on the external one it works fine. On the other hand, there is an image on the matrix on others, but after 1 minute the fans turn on at full speed and after 5 minutes the laptop turns off.

Layout Cast:
CPU: SRG26
GPU: N17P-G0-K1-A1
PCH/FCH: SR40B
KBC: IT8586E FXS
BIOS UC3/BIOS: 25Q128JVSQ
In the attachment, the original BIOS on which it switches off



[ThienBui]

I am looking for a Biosu / EC for this Lenovo L340-17IRH laptop FG541 / FG741 NM-C362 REV.1.0 2019-03-19 motherboard.
I tried various available ones and the problem with them is that on some the laptop does not display the image on the matrix, but on the external one it works fine. On the other hand, there is an image on the matrix on others, but after 1 minute the fans turn on at full speed and after 5 minutes the laptop turns off.

Layout Cast:
CPU: SRG26
GPU: N17P-G0-K1-A1
PCH/FCH: SR40B
KBC: IT8586E FXS
BIOS UC3/BIOS: 25Q128JVSQ
In the attachment, the original BIOS on which it switches off

you want I help what ?



[dzaro5]

you want I help what ?

I am looking for a bios feed that will work



[ThienBui]

I am looking for a bios feed that will work

above many BIOS ok
